10M FTTH Fiber Patch Cord With SC / APC Singlemode Mutimode Simplex Duplex

Brand Name : TTI

Model Number : Fiber Optic Patch Cord

Certification : CE, ROSH

Place of Origin : Guangdong, China

MOQ : Negotiable

Price : Negotiable

Payment Terms : T/T, , , paypal

Supply Ability : 8000pcs/day

Delivery Time : 3-5days

Packaging Details : in pp bag then in cartons

color : Orange, yellow, blue, aqua

Material : PVC or LSZH

Diameter : 0.9mm/2.0mm/3.0mm

Connector : FC,LC,SC,ST,MPO

Polish : PC/UPC/APC

Contact Now

10M FTTH Fiber Patch Cord With SC / APC Singlemode Mutimode Simplex Duplex

Description:

Type: SC/APC-SC/APC-SM-DX-3.0mm-10M
Mode: Singlemode
Ferrule End-face: APC
Cable core: Duplex
Cable diameter: 2.0mm, 3.0mm
Cable length: 1m, 2m, 3m….customized

Application:

Telecommunication
CATV, FTTH, LAN
Fiber oiptic sensors
Optical transmission system
Test equipment

Features:

Screw-thread coupling mechanism
Ceramic ferrules connectors
Low insertion loss, high return loss
Excellent mechanical endurance
High credibility and stability
Good in repeatability and exchangeability
100% Insertion, Return Loss, End Face and Interference inspection

Parameter:

Insertion losses	G652D	dB	≤ 0.2
Return losses	G652D	dB	≥ 60
Attenuation		dB/Km	0,3
Connectors		type	SC/APC
Fiber		type	Monomode (SM) G652
Outer sheath		material	LSZH PVC
		Ø mm	3
		color	Orange
Available jumper lengths		m	10

Ordering Information

Connector	Fiber Core	Cable Diameter	Fiber Type	Polishing	Cable Jacket	Cable Color	Fiber Length
LC SC FC ST MU MPO MTRJ	Simplex Duplex	0.9mm 2.0mm 3.0mm	SM:9/125um MM:50/125um MM:62.5/125um OM3	PC UPC APC	PVC LSZH	Yellow Orange Aqua others	1M 2M 3M 10M 20M 30M

10M FTTH Fiber Patch Cord With SC / APC Singlemode Mutimode Simplex Duplex
